SD LED Controller

This version of SD card controls both DMX compatible LED lighting products as well as those with driver chips like WS2811,WS2801,WS2803,WS2803,to name a few.

Features

This controller reads SD cards that store programs for lighting.

It’s applicable for LED lighting items with single- and double-wire driver chips.

The driver chip controllable includes DMX512,WS2811,WS2801,WS2803,BS0815 etc.

This controller stores a maximum of 16 programs,copy multiple files to the SD card in order, (00_1.led, 01_1.led, 02_led…) after formatting the SD card as“FAT”format.

TTL signal（245/spi signal）：RS485 signal

NOTE：For TTL (SPI) signal, the controller ground signal must be connected to the LED ground directly.

Technical Specs

Connection Guide

SD card controller is applicable for varieties of LED lighting items.It has the version that controls non-DMX lighting and another version specially used for DMX compatible LED lighting. Program files are stored in high speed SD card.

Features

This controller is used for controlling different LED lighting with a wide range of driver chips: WS2811,WS2801,WS2803,TM1903,APA102,etc.

Each of the 8-port controller controls up to 1024 pixels.

One controller is able to work with another by connecting in series.The distance between two linked controllers is up to 200 meters.

This controller stores a maximum of 16 programs, copy multiple files to the SD card in order,(00_1.led, 01_1.led, 02_led…) after formatting the SD card as “FAT” format.

It’s applicable for LED lighting items with single-and double-wire driver chips

Technical Specs

DMX Version

This is the version of SD Card controller that works for DMX LED lighting only. Each of the 8 ports controls up to 270 pixels.

Signal Output (DMX):

Connection Guid

Similar Products：

Real Time LED Controller

Master-Slave Controller
